QSC K 10.2
Configuration: 2-way multifunction loudspeaker
LF driver: 10" (254mm)
HF driver: 1.4" compression driver (35.6mm) with Titanium diaphragm
Frequency response (-6dB): 56Hz - 20kHz
Frequency range (-10dB): 50Hz - 20kHz
Nominal coverage angle: 90° Axisymmetric
Nominal max SPL: 130dB @ 1m, peak 124 dB @ 1m, continuous
Amplifier: 1800W (LF), 225W (HF) in Class D
Cooling: Variable-speed low-noise fan
Controls: Power, 3x Level, Rotary encoder (push), 2x selection buttons
Indicators: LCD display 1.75" x 1", 2 Power LEDs (front and rear), 3 Input Signal LEDs, Input Mic LED, Input Hi-Z LED, Limiter LED
Connectors: 2x XLR/F, 1/4" Combo (Mic/Line and Hi-Z/Line), 1x 3.5mm TRS, 2x XLR/M (Output Loop-Thru), 1x XLR/M (Output Mix)
Power: 100 - 240V, 50 - 60Hz
Cabinet: ABS impact resistant
Attachment points: 2x M10 plus Pull-Back
Color: Black (RAL 9011)
Grille: Steel with coating
Dimensions: 519 x 320 x 300mm
Weight: 14.5kg
